MPL-AL5030

Molded Construction
Magnetically Shielded

High Performance
Low AC/DCR Losses

Soft Saturation
Stable Over High Temperatures

The MPL-AL Series offers Low DCR/ACR and a flat-wire construction, which provides even higher current ratings than round-wire molded inductors.

电感选择工具

Buck Sync Image Buck Non-Sync Image Boost Sync Image Boost Non-Sync Image
基于额定数值进行计算
参数显示栏
状态
MPS Inventory
L (µH)
RDC(典型值)(mΩ)
IR (40K) (A)
饱和电流(30%)(A)
最大工作温度(°C)
A 尺寸(长)(mm)
B 尺寸(宽)(mm)
C 尺寸(高)(mm)
结构
MPSafe
MPL
Product URL
L (µH)
RDC(典型值)(mΩ)
IR (40K) (A)
饱和电流(30%)(A)
最大工作温度(°C)
A 尺寸(长)(mm)
B 尺寸(宽)(mm)
C 尺寸(高)(mm)
结构
Buy On MPS
0.47
0.56
0.82
1.0
1.2
1.5
1.8
2.2
3.3
4.7
+155°C
5.50
5.30
2.90
SMD
Is MPSafe Has MPL Product URL

MPL-AL5030-3R3

薄型塑封电感 3.3µH

Buy On MPS 3.3 21 6.0 10 155°C 5.50 5.30 2.90 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-al5030-3r3.html
MPL-AL5030-4R7

薄型塑封电感 4.7µH

Buy On MPS 4.7 33 5.3 8 155°C 5.50 5.30 2.90 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-al5030-4r7.html
MPL-AL5030-1R0

薄型塑封电感 1.0µH

Buy On MPS 1.0 6.5 11.2 16 155°C 5.50 5.30 2.90 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-al5030-1r0.html
MPL-AL5030-1R2

薄型塑封电感 1.2µH

Buy On MPS 1.2 8.0 10.0 14 155°C 5.50 5.30 2.90 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-al5030-1r2.html
MPL-AL5030-1R5

薄型塑封电感 1.5µH

Buy On MPS 1.5 9.7 9.0 12.5 155°C 5.50 5.30 2.90 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-al5030-1r5.html
MPL-AL5030-1R8

薄型塑封电感 1.8µH

Buy On MPS 1.8 10.5 8.8 12 155°C 5.50 5.30 2.90 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-al5030-1r8.html
MPL-AL5030-2R2

薄型塑封电感2.2µH

Buy On MPS 2.2 12.3 8.2 11 155°C 5.50 5.30 2.90 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-al5030-2r2.html
MPL-AL5030-R47

薄型塑封电感 0.47µH

Buy On MPS 0.47 3.78 13.6 26.5 155°C 5.50 5.30 2.90 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-al5030-r47.html
MPL-AL5030-R56

薄型塑封电感 0.56µH

Buy On MPS 0.56 3.92 13.2 22 155°C 5.50 5.30 2.90 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-al5030-r56.html
MPL-AL5030-R82

薄型塑封电感 0.82µH

Buy On MPS 0.82 5.0 12.8 18 155°C 5.50 5.30 2.90 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-al5030-r82.html
No more part left for display.
