用于MPS DCDC产品的一体成型电感

一体成型结构
磁屏蔽

低阻抗
大电流能力

性能最优
高效率

此类一体成型磁屏蔽功率电感,软饱和感量特性良好,高温性能稳定,可以降低交流电和脉冲波频率所产生的音频噪声。

电感选择工具

Buck Sync Image Buck Non-Sync Image Boost Sync Image Boost Non-Sync Image
基于额定数值进行计算
参数显示栏
状态
MPS库存
系列
L (µH)
RDC(典型值)(mΩ)
IR (40K) (A)
饱和电流(30%)(A)
最大工作温度(°C)
A 尺寸(长)(mm)
B 尺寸(宽)(mm)
C 尺寸(高)(mm)
结构
MPSafe
MPL
Product URL
系列
L (µH)
RDC(典型值)(mΩ)
IR (40K) (A)
饱和电流(30%)(A)
最大工作温度(°C)
A 尺寸(长)(mm)
B 尺寸(宽)(mm)
C 尺寸(高)(mm)
结构
从MPS官网购买
Molded Low Profile
Molded Low Resistance
Molded
0.33
0.47
0.56
0.68
0.82
1.0
1.2
1.5
1.8
10
15
2.2
22
3.3
4.7
5.6
6.8
8.2
0.89
1.1
1.25
1.3
1.5
1.75
1.8
10.1
10.5
11.7
12
12.2
12.3
12.5
121
129
13
13.3
13.5
136
137
14.5
15
16
16.5
163
173
180
19
19.5
2.3
2.6
20
209
21
21.5
21.8
215
24
25
250
26
27
28
280
3.3
3.4
3.7
3.78
3.9
3.92
30
31.4
33
34.5
345
35
355
37
370
4.3
4.9
41
5.0
5.3
5.5
50
52.2
56
6.0
6.2
6.5
64
7.0
7.5
70
8
8.0
8.3
8.6
9.0
9.5
9.7
9.9
97
1.2
1.3
1.4
1.5
1.65
1.7
1.8
1.90
10.0
10.1
10.7
11.2
11.5
12
12.0
12.5
12.8
13
13.2
13.3
13.6
14
14.6
15
16
16.2
16.9
17
19
2.0
2.10
2.2
2.20
2.4
2.45
2.5
2.6
20
22
23
24
25
25.5
27
29
3.0
3.2
3.4
3.5
3.65
31
33
4.0
4.3
4.4
4.7
4.8
5.15
5.3
5.5
5.8
6.0
6.1
6.3
6.4
6.8
6.9
7
7.4
7.5
7.8
7.9
8.0
8.2
8.4
8.5
8.7
8.8
9
9.0
9.2
9.4
9.8
1.7
1.75
1.9
1.95
10
11
12
12.5
13
14
15
16
17
18
19.5
2
2.1
2.2
2.4
2.6
2.7
2.8
20
21
22
23
24
25
26.5
29
3.1
3.2
3.4
3.7
33
34
36
37
4.2
4.9
41
43
46
5.2
5.3
5.5
5.7
5.9
51
58
6
6.2
6.4
6.6
64
7
7.1
7.2
7.5
7.6
8
8.5
8.6
9
9.5
+125°C
+155°C
SMD
Is MPSafe Has MPL Product URL

MPL-AL4020-1R0

低阻抗塑封电感 1.0µH

从MPS官网购买 Molded Low Resistance 1.0 10.1 7.9 8.6 155°C 4.10 4.10 1.90 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-al4020-1r0.html
MPL-AY3020-5R6

塑封电感 5.6µH

从MPS官网购买 Molded 5.6 209 1.8 2.8 125°C 3.5 3.2 1.8 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay3020-5r6.html
MPL-AY1050-R68

塑封电感 0.68µH

从MPS官网购买 Molded 0.68 1.75 23 36 155°C 11.0 10.0 4.80 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay1050-r68.html
MPL-AY1050-R47

塑封电感 0.47µH

从MPS官网购买 Molded 0.47 1.25 25 41 155°C 11.0 10.0 4.80 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay1050-r47.html
MPL-AY4020-100

塑封电感 10µH

从MPS官网购买 Molded 10 163 1.90 2 155°C 4.45 4.1 1.80 SMD 1 0 https://www.monolithicpower.cn/cn/mpl-ay4020-100.html
MPL-AY4020-8R2

塑封电感 8.2µH

从MPS官网购买 Molded 8.2 136 2.10 2.1 155°C 4.45 4.1 1.80 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay4020-8r2.html
MPL-AY4020-6R8

塑封电感 6.8µH

从MPS官网购买 Molded 6.8 129 2.20 2.4 155°C 4.45 4.1 1.80 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay4020-6r8.html
MPL-AY4020-5R6

塑封电感 5.6µH

从MPS官网购买 Molded 5.6 97 2.45 2.6 155°C 4.45 4.1 1.80 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay4020-5r6.html
MPL-AY3020-100

塑封电感 10µH

从MPS官网购买 Molded 10 370 1.3 1.75 125°C 3.5 3.2 1.8 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay3020-100.html
MPL-AY3020-8R2

塑封电感 8.2µH

从MPS官网购买 Molded 8.2 345 1.4 1.95 125°C 3.5 3.2 1.8 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay3020-8r2.html
MPL-AY3020-6R8

塑封电感 6.8µH

从MPS官网购买 Molded 6.8 250 1.65 2.6 125°C 3.5 3.2 1.8 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay3020-6r8.html
MPL-AY3020-4R7

塑封电感 4.7µH

从MPS官网购买 Molded 4.7 173 2.0 3.1 125°C 3.5 3.2 1.8 SMD 1 0 https://www.monolithicpower.cn/cn/mpl-ay3020-4r7.html
MPL-AY1050-1R5

塑封电感 1.5µH

从MPS官网购买 Molded 1.5 3.4 17 26.5 155°C 11.0 10.0 4.80 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay1050-1r5.html
MPL-AY3020-3R3

塑封电感 3.3µH

从MPS官网购买 Molded 3.3 121 2.5 3.7 125°C 3.5 3.2 1.8 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay3020-3r3.html
MPL-AY3020-2R2

塑封电感 2.2µH

从MPS官网购买 Molded 2.2 64 3.0 5.3 125°C 3.5 3.2 1.8 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay3020-2r2.html
MPL-AY3020-1R5

塑封电感 1.5µH

从MPS官网购买 Molded 1.5 35 3.4 5.9 125°C 3.5 3.2 1.8 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay3020-1r5.html
MPL-AY3020-1R0

塑封电感 1.0µH

从MPS官网购买 Molded 1.0 30 4.3 6.2 125°C 3.5 3.2 1.8 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay3020-1r0.html
MPL-AY3020-R82

塑封电感 0.82µH

从MPS官网购买 Molded 0.82 28 4.7 8 125°C 3.5 3.2 1.8 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay3020-r82.html
MPL-AY3020-R68

塑封电感 0.68µH

从MPS官网购买 Molded 0.68 26 5.15 8.6 125°C 3.5 3.2 1.8 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay3020-r68.html
MPL-AY3020-R47

塑封电感 0.47µH

从MPS官网购买 Molded 0.47 19.5 6.3 9 125°C 3.5 3.2 1.8 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay3020-r47.html
MPL-AL6060-150

薄型塑封电感 15µH

从MPS官网购买 Molded Low Resistance 15 35 5.8 5.5 155°C 6.60 6.40 5.80 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-al6060-150.html
MPL-AL6060-100

薄型塑封电感 10µH

从MPS官网购买 Molded Low Resistance 10 24 6.9 6.6 155°C 6.60 6.40 5.80 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-al6060-100.html
MPL-AY1050-1R0

塑封电感 1.0µH

从MPS官网购买 Molded 1.0 2.6 19 33 155°C 11.0 10.0 4.80 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay1050-1r0.html
MPL-AY1050-2R2

塑封电感 2.2µH

从MPS官网购买 Molded 2.2 4.9 15 19.5 155°C 11.0 10.0 4.80 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay1050-2r2.html
MPL-AL6060-6R8

薄型塑封电感 6.8µH

从MPS官网购买 Molded Low Resistance 6.8 16 8.5 8 155°C 6.60 6.40 5.80 SMD 1 0 https://www.monolithicpower.cn/cn/mpl-al6060-6r8.html
MPL-AY1265-1R5

塑封电感 1.5µH

从MPS官网购买 Molded 1.5 2.3 22 34 155°C 13.50 12.60 6.20 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay1265-1r5.html
MPL-AY1265-150

塑封电感 15µH

从MPS官网购买 Molded 15 21.8 8.5 12 155°C 13.50 12.60 6.20 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay1265-150.html
MPL-AY1265-100

塑封电感 10µH

从MPS官网购买 Molded 10 13.3 10.7 16 155°C 13.50 12.60 6.20 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay1265-100.html
MPL-AY1265-8R2

塑封电感 8.2µH

从MPS官网购买 Molded 8.2 12.5 11.5 18 155°C 13.50 12.60 6.20 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay1265-8r2.html
MPL-AY1265-6R8

塑封电感 6.8µH

从MPS官网购买 Molded 6.8 9.9 12 19.5 155°C 13.50 12.60 6.20 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay1265-6r8.html
MPL-AY1265-5R6

塑封电感 5.6µH

从MPS官网购买 Molded 5.6 8.6 13 20 155°C 13.50 12.60 6.20 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay1265-5r6.html
MPL-AY1265-4R7

塑封电感 4.7µH

从MPS官网购买 Molded 4.7 7.0 14 23 155°C 13.50 12.60 6.20 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay1265-4r7.html
MPL-AY1265-3R3

塑封电感 3.3µH

从MPS官网购买 Molded 3.3 5.5 16 25 155°C 13.50 12.60 6.20 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay1265-3r3.html
MPL-AY1265-2R2

塑封电感 2.2µH

从MPS官网购买 Molded 2.2 3.7 17 26.5 155°C 13.50 12.60 6.20 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay1265-2r2.html
MPL-AY1265-1R8

塑封电感 1.8µH

从MPS官网购买 Molded 1.8 3.3 20 29 155°C 13.50 12.60 6.20 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay1265-1r8.html
MPL-AY1265-1R2

塑封电感 1.2µH

从MPS官网购买 Molded 1.2 1.8 24 37 155°C 13.50 12.60 6.20 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay1265-1r2.html
MPL-AY1050-3R3

塑封电感 3.3µH

从MPS官网购买 Molded 3.3 8 12.5 17 155°C 11.0 10.0 4.80 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay1050-3r3.html
MPL-AY1265-1R0

塑封电感 1.0µH

从MPS官网购买 Molded 1.0 1.5 25.5 43 155°C 13.50 12.60 6.20 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay1265-1r0.html
MPL-AY1265-R82

塑封电感 0.82µH

从MPS官网购买 Molded 0.82 1.3 27 46 155°C 13.50 12.60 6.20 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay1265-r82.html
MPL-AY1265-R68

塑封电感 0.68µH

从MPS官网购买 Molded 0.68 1.25 29 51 155°C 13.50 12.60 6.20 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay1265-r68.html
MPL-AY1265-R56

塑封电感 0.56µH

从MPS官网购买 Molded 0.56 1.1 31 58 155°C 13.50 12.60 6.20 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay1265-r56.html
MPL-AY1265-R47

塑封电感 0.47µH

从MPS官网购买 Molded 0.47 0.89 33 64 155°C 13.50 12.60 6.20 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay1265-r47.html
MPL-AY1050-100

塑封电感 10µH

从MPS官网购买 Molded 10 19 7.8 12 155°C 11.0 10.0 4.80 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay1050-100.html
MPL-AY1050-6R8

塑封电感 6.8µH

从MPS官网购买 Molded 6.8 15 9 13 155°C 11.0 10.0 4.80 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay1050-6r8.html
MPL-AY1050-5R6

塑封电感 5.6µH

从MPS官网购买 Molded 5.6 13 9.8 14 155°C 11.0 10.0 4.80 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay1050-5r6.html
MPL-AY1050-4R7

塑封电感 4.7µH

从MPS官网购买 Molded 4.7 9.5 11.5 15 155°C 11.0 10.0 4.80 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-ay1050-4r7.html
MPL-AL6060-8R2

薄型塑封电感 8.2µH

从MPS官网购买 Molded Low Resistance 8.2 19 8.0 7 155°C 6.60 6.40 5.80 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-al6060-8r2.html
MPL-AL6060-5R6

薄型塑封电感 5.6µH

从MPS官网购买 Molded Low Resistance 5.6 13 9.4 8.6 155°C 6.60 6.40 5.80 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-al6060-5r6.html
MPL-AT2010-R47

薄型塑封电感 0.47µH

从MPS官网购买 Molded Low Profile 0.47 27 4.4 5.7 125°C 2.0 1.60 1.0 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-at2010-r47.html
MPL-AT2514-2R2

薄型塑封电感 2.2µH

从MPS官网购买 Molded Low Profile 2.2 70 2.6 3.4 125°C 2.50 2.0 1.40 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-at2514-2r2.html
MPL-AL4020-1R5

低阻抗塑封电感 1.5µH

从MPS官网购买 Molded Low Resistance 1.5 14.5 6.4 7.1 155°C 4.10 4.10 1.90 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-al4020-1r5.html
MPL-AL4020-1R2

低阻抗塑封电感 1.2µH

从MPS官网购买 Molded Low Resistance 1.2 12.2 7.4 7.5 155°C 4.10 4.10 1.90 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-al4020-1r2.html
MPL-AL4020-R82

低阻抗塑封电感 0.82µH

从MPS官网购买 Molded Low Resistance 0.82 9.0 8.4 9.5 155°C 4.10 4.10 1.90 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-al4020-r82.html
MPL-AL4020-R68

低阻抗塑封电感 0.68µH

从MPS官网购买 Molded Low Resistance 0.68 7.5 8.7 11 155°C 4.10 4.10 1.90 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-al4020-r68.html
MPL-AL4020-R47

低阻抗塑封电感 0.47µH

从MPS官网购买 Molded Low Resistance 0.47 6.2 9.2 12.5 155°C 4.10 4.10 1.90 SMD 1 0 https://www.monolithicpower.cn/cn/mpl-al4020-r47.html
MPL-AT2512-100

薄型塑封电感 10µH

从MPS官网购买 Molded Low Profile 10 355 1.2 1.7 125°C 2.50 2.0 1.20 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-at2512-100.html
MPL-AT2512-6R8

薄型塑封电感 6.8µH

Molded Low Profile 6.8 280 1.4 2.2 125°C 2.50 2.0 1.20 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-at2512-6r8.html
MPL-AT2514-4R7

薄型塑封电感 4.7µH

从MPS官网购买 Molded Low Profile 4.7 180 1.7 2.4 125°C 2.50 2.0 1.40 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-at2514-4r7.html
MPL-AT2512-3R3

薄型塑封电感 3.3µH

从MPS官网购买 Molded Low Profile 3.3 121 2.0 2.7 125°C 2.50 2.0 1.20 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-at2512-3r3.html
MPL-AT2512-1R5

薄型塑封电感 1.5µH
