REFERENCE DESIGN

---

参考设计

MPS提供的AMD Xilinx Zynq-7000 SoC参考设计以MPM54304四路PMIC模块为中心，还有两个LDO稳压器用于向Zynq SoC提供所有电源轨。MPM54304具有4路输出（3A / 3A / 2A / 2A），可以并联使用以实现设计灵活性，而且内置电源排序。该设计可以在4V至16V输入电压范围内工作。

REFERENCE DESIGN

---

参考设计

The MPS Industrial Ethernet Reference design for the AMD Xilinx Zynq-7000 SoC combines a small footprint with good efficiency and tight regulation. Three MPM3630 3 amp buck modules combine with an MPM3610 1 amp buck module and two LDO regulators to provide power rails to the Zynq SoC. The output rails are from 0.75V to 3.3V, from a 12V input supply.
