Fast turn off, Intelligent Synchronous Rectifier with Vfwd=30mV for flyback converters
产品描述
The MP6905 is a low-drop, diode-emulator IC with external switch; MP6905 replaces Schottky diodes in high-efficiency, flyback converters. The chip regulates the forward drop of the external switch (about 30mV) and switches it off when the voltage becomes negative. MP6905 has a light-load sleep mode that reduces the quiescent current to <300uA.
MP6905 is available in a compact SOIC-8 package.
产品特性
- Works with 12V Standard and 5V Logic Level FETS
- Compatible with Energy Star, 1W Standby Requirements
- Fast Turn-off, Total Delay 20ns
- Supports CCM, DCM and Quasi-Resonant Topologies
- Supports High-side and Low-side Rectification
- Saves Up to 1.5W in a Typical Notebook Adapter
- Available in a SOIC-8 Package
技术参数
- fsw (max) (kHz)400
- Iq (mA)2
- Iop (mA)8
- Drain Rating180
- VDD (min) (V)8
- VDD (max) (V)24
- Pout (max) (W)150
- PackageSOIC8-7
- TypeController
- GradeCatalog
- Light-Load FunctionYes
- Power Range DefinedYes
