MPL-SE2512

半屏蔽式结构
漏磁小
低阻抗
大电流能力
多种感值和体积可选

MPL-SE半屏蔽式功率电感外部使用电磁环氧树脂材料,具有更好的导磁特性,降低了DCR,提高了电流能力。

电感选择工具

Buck Sync Image Buck Non-Sync Image Boost Sync Image Boost Non-Sync Image
基于额定数值进行计算
参数显示栏
状态
MPS Inventory
L (µH)
RDC(典型值)(mΩ)
IR (40K) (A)
饱和电流(30%)(A)
最大工作温度(°C)
A 尺寸(长)(mm)
B 尺寸(宽)(mm)
C 尺寸(高)(mm)
结构
MPSafe
MPL
Product URL
L (µH)
RDC(典型值)(mΩ)
IR (40K) (A)
饱和电流(30%)(A)
最大工作温度(°C)
A 尺寸(长)(mm)
B 尺寸(宽)(mm)
C 尺寸(高)(mm)
结构
Buy On MPS
0.47
0.68
1.0
1.5
10
15
2.2
22
3.3
4.7
6.8
+125°C
2.5
2.0
1.2
SMD
Is MPSafe Has MPL Product URL

MPL-SE2512-R47

半屏蔽电感 0.47µH

Buy On MPS 0.47 20 4.5 6.5 125°C 2.5 2.0 1.2 SMD 1 0 https://www.monolithicpower.cn/cn/mpl-se2512-r47.html
MPL-SE2512-R68

半屏蔽电感 0.68µH

Buy On MPS 0.68 28 3.9 5 125°C 2.5 2.0 1.2 SMD 1 0 https://www.monolithicpower.cn/cn/mpl-se2512-r68.html
MPL-SE2512-3R3

半屏蔽电感 3.3µH

3.3 90 2.1 2.4 125°C 2.5 2.0 1.2 SMD 1 0 https://www.monolithicpower.cn/cn/mpl-se2512-3r3.html
MPL-SE2512-1R5

半屏蔽电感1.5µH

Buy On MPS 1.5 50 2.9 3.2 125°C 2.5 2.0 1.2 SMD 1 0 https://www.monolithicpower.cn/cn/mpl-se2512-1r5.html
MPL-SE2512-1R0

半屏蔽电感 1.0µH

Buy On MPS 1.0 35 3.4 4.2 125°C 2.5 2.0 1.2 SMD 1 0 https://www.monolithicpower.cn/cn/mpl-se2512-1r0.html
MPL-SE2512-2R2

半屏蔽电感 2.2µH

Buy On MPS 2.2 72 2.5 2.7 125°C 2.5 2.0 1.2 SMD 1 0 https://www.monolithicpower.cn/cn/mpl-se2512-2r2.html
MPL-SE2512-4R7

半屏蔽电感 4.7µH

Buy On MPS 4.7 165 1.6 1.9 125°C 2.5 2.0 1.2 SMD 1 0 https://www.monolithicpower.cn/cn/mpl-se2512-4r7.html
MPL-SE2512-100

半屏蔽电感10µH

Buy On MPS 10 410 1.1 1.3 125°C 2.5 2.0 1.2 SMD 1 0 https://www.monolithicpower.cn/cn/mpl-se2512-100.html
MPL-SE2512-150

半屏蔽电感 15µH

Buy On MPS 15 620 0.85 0.9 125°C 2.5 2.0 1.2 SMD 1 0 https://www.monolithicpower.cn/cn/mpl-se2512-150.html
MPL-SE2512-220

半屏蔽电感 22µH

Buy On MPS 22 885 0.7 0.8 125°C 2.5 2.0 1.2 SMD 1 0 https://www.monolithicpower.cn/cn/mpl-se2512-220.html
MPL-SE2512-6R8

半屏蔽电感6.8μH

Buy On MPS 6.8 305 1.2 1.6 125°C 2.5 2.0 1.2 SMD 1 0 https://www.monolithicpower.cn/cn/products/inductor/shielded-optimized-for-mps-dc-dc/mpl-se2512-6r8.html
无更多产品显示
