MP8869W

正在供货

High-Efficiency, 12A, 18V, Synchronous Step-Down Converter with I2C Interface



了解更多我们的评估板套件
咨询工程师或询价

产品描述

The MP8869W is a high-frequency, synchronous, rectified, step-down, switch-mode converter with I2C control interface. It offers a fully integrated solution to achieve a 12A continuous and 15A peak output current with excellent load and line regulation over a wide input supply range. In the I2C control loop, the output voltage level can be controlled on the fly through an I2C serial interface. The voltage range can be adjusted from 0.6V to 1.55V in 7.5mV steps. The voltage slew rate, frequency, current limit, hiccup/latch-off protection, enable, and power savings mode are also selectable through the I2C interface. COT control operation provides fast transient response. An open-drain power good pin indicates that the output voltage is in the nominal range. Full protection features include over-voltage protection, over-current protection, and thermal shutdown. The MP8869W is available in a QFN-14 (3mmx4mm) package.

产品特性

  • Wide, 3V to 18V Operating Input Range
  • 12A Continuous/15A Peak Output Current
  • 1% Internal Reference Accuracy
  • I2C Programmable Output Range from 0.6V to 1.55V in 7.5mV Steps with Slew Rate Control
  • 5% Accuracy Output Voltage and Output Current Read Back via I2C
  • Selectable PFM/PWM Mode and Adjustable Frequency & Current Limit through I2C
  • 4 Different Selectable I2C Addresses
  • External Soft Start
  • Open-Drain Power Good Indication
  • Output Over-Voltage Protection
  • Hiccup/Latch-Off OCP Protection
  • QFN-14 (3mmx4mm) Package

技术参数

  • fsw (max) (kHz)1250
  • 最小输入电压3
  • Vin (max) (V)18
  • Iout (max) (A)12
  • Isw Limit (typ) (A)14
  • Vfb (V)0.6
  • Iq (typ) (mA)0.42
  • 额定输出1
  • Vout (max) (V)5.5
  • Vout (min) (V)0.6
  • GradeCatalog
  • PackageQFN-14 (3x4)
  • Control ModeCOT
  • Common FeaturesExternal Soft Start, Light-Load Efficiency, Power Good, Synchronous Rectification
  • Special Features4 种不同的 I2C 地址可选, 5% Accuracy Output Voltage and Output Current Readback via I2C, I2C Interface, Programmable Frequency, Programmable Output Voltage, Selectable Current Limit, Selectable PFM/PWM Mode

3V-18V, 12A, High-Efficiency, Wide-Input, Synchronous, Step-Down Converter

The MP8869W is a high-frequency, synchronous, rectified, step-down, switch-mode converter with an I2C control interface. The MP8869W offers a fully integrated solution that achieves 12A of continuous and 15A of peak output current with excellent load and line regulation over a wide input supply range.

Highly customizable, the MP8869W is capable of supporting a diverse array of applications. Users can program it via MPS I2C GUI; however, changes made in I2C mode will not be retained once the EVB is powered down.

The EVKT8869W is a valuable evaluation tool well-suited for all types of experience levels, from beginner to expert, and can help users quickly determine if the MP8869W is right for their target application.

¥ 513.75 + tax



High Efficiency, 12A, 17V, Synchronous Step-Down Converter with I2C Interface

The EV8869W-L-00A is used for demonstrating the performance of MPS’s MP8869W. MP8869W is a highly integrated and high frequency synchronous step-down switcher with I2C control interface. It is optimized to support up to 12A continuous/15A peak output current over an input supply range from 3V to 18V with excellent load and line regulation.

COT control operation provides fast transient response and eases loop stabilization. In I2C control loop, the output voltage level can be controlled, on-the fly through an I2C serial interface. Output voltage range can be adjusted from 0.6V to 1.55V in 7.5mV steps. Voltage scaling slew rate, enable and power saving mode are also selectable through the I2C interface. Full protection features include over voltage, over-current protection and thermal shut down.

The MP8869W is available in QFN-14(3mmx4mm) package.

¥ 171.25 + tax



Configure multiple parameters of the MP88xx including output voltage and fsw.

This I2C GUI allows you to program the MP88xx . By using this I2C GUI, you can set the output voltage, switching frequency, slew rate, and operation mode. Please reference the parts respective user guides for installation and programing instructions.

System Requirements:

Windows 7 or later

.Net Framework 4 or later



USB 转 I2C/PMBus 通信接口设备,包含在产品评估套件中,也可单独购买

EVKT-USBI2C-02 包含在产品评估套件中,也可单独购买。该通信接口同时兼容USB 转 I2C 端口和 USB 转 PMBus 端口。它是设计用于 MPS I2C 和 PMBus 产品和虚拟平台及 I2C GUI 工具上。与 MPS 虚拟平台和 I2C GUI一起使用可以简单快速地评估 MPS 的数字产品性能。

EVKT-USBI2C-02 套件包括:

  • 1 个 USB 转 I2C 通信设备接口
  • 1 根 USB 线
  • 1 根 10 芯排线
  • 1 根 3 芯排线
  • 带有规格书和驱动文件的拇指驱动

¥ 171.25 + tax
