MPL-AL5050

Molded Construction
Magnetically Shielded

High Performance
Low AC/DCR Losses

Soft Saturation
Stable Over High Temperatures

The MPL-AL Series offers Low DCR/ACR and a flat-wire construction, which provides even higher current ratings than round-wire molded inductors.

电感选择工具

Buck Sync Image Buck Non-Sync Image Boost Sync Image Boost Non-Sync Image
基于额定数值进行计算
参数显示栏
状态
MPS Inventory
L (µH)
RDC(典型值)(mΩ)
IR (40K) (A)
饱和电流(30%)(A)
最大工作温度(°C)
A 尺寸(长)(mm)
B 尺寸(宽)(mm)
C 尺寸(高)(mm)
结构
MPSafe
MPL
Product URL
L (µH)
RDC(典型值)(mΩ)
IR (40K) (A)
饱和电流(30%)(A)
最大工作温度(°C)
A 尺寸(长)(mm)
B 尺寸(宽)(mm)
C 尺寸(高)(mm)
结构
Buy On MPS
10
5.6
6.8
8.2
+155°C
5.50
5.30
4.80
SMD
Is MPSafe Has MPL Product URL

MPL-AL5050-5R6

薄型款注塑塑封电感 5.6µH

Buy On MPS 5.6 20 6.8 8 155°C 5.50 5.30 4.80 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-al5050-5r6.html
MPL-AL5050-6R8

薄型款注塑塑封电感 6.8µH

Buy On MPS 6.8 25 6.1 7.6 155°C 5.50 5.30 4.80 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-al5050-6r8.html
MPL-AL5050-8R2

薄型款注塑塑封电感 8.2µH

Buy On MPS 8.2 28 5.8 7.2 155°C 5.50 5.30 4.80 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-al5050-8r2.html
MPL-AL5050-100

薄型款注塑塑封电感 10µH

Buy On MPS 10 37 4.8 5.5 155°C 5.50 5.30 4.80 SMD 0 0 https://www.monolithicpower.cn/cn/mpl-al5050-100.html
No more part left for display.
