- MPM3896-30
MPM3896-30
Session textval
Session Titefor popup
详情
The MPM3896-30 is a fully integrated, stackable, synchronous buck module series with a PMBus interface. It offers a complete power solution that integrates a controller, half-bridge FET, and power inductor, offering excellent load and line regulation across a wide 2.8V to 6V input voltage (VIN) range and 0.3V to 0.9 x VIN output voltage (VOUT) range. The MPM3896-30 operates at high efficiency across a wide output current (IOUT) range.
The device adopts MPS’s proprietary, constant-on-time (COT) control, which provides ultra-fast transient response and minimizes the required output capacitance. The PMBus interface provides digital configurability and key parameter monitoring.
It also features rich protection functions, including over-current protection (OCP), over-voltage protection (OVP), under-voltage protection (UVP), and over-temperature protection (OTP).
The MPM3896-30 requires a minimal number of readily available external components, and is available in a compact ECLGA (5mmx6mm) package.
-
显示更多
显示较少
产品特性和优势
- Wide 2.8V to 6V Operating Input Voltage (VIN) Range:
- 3.5V to 6V without VDD33 Connected to 3.3V
- 2.8V to 3.5V with VDD33 Connected to 3.3V
- Adjustable Output Voltage (VOUT) from 0.3V to 0.9 x VIN
- 30A Continuous Output Current (IOUT)
- VOUT Remote Sense
- Lossless, Accurate On-Die Current-Sensing
- 300kHz to 2MHz Switching Frequency (fSW)
- Ultra-Fast Transient Response with Multi-Phase Constant-On-Time (MCOT) Control
- Tracking Function Available
- PMBus 1.3 Compliant
- Configurable via the PMBus:
- Load Line
- Compensation
- VOUT
- fSW
- Protection Threshold and Mode
- Built-In Multiple-Time Programmable (MTP) Memory to Store Custom Configurations
- Accurate Telemetry Including:
- VIN and VOUT
- IOUT
- Fault Report
- Temperature
- Available in a Compact ECLGA (5mmx6mmx2.9mm) Package

正在供货产品型号
MPM3896GPJ-30-xxxx-T MPM3896GPJ-30-0000-T
