MPQ5071N-AEC1

MPQ5071N-AEC1

5.5V, 1A Load Switch, AEC-Q100 Qualified

详情

The MPQ5071N-AEC1 is a load switch designed to provide 1A of load protection across 0.5V to 5.5V input voltage (V_IN) range. With the small on resistance (R_DS(ON)) in a tiny SOT563 package, it provides a highly efficient, space-saving solution for infotainment, advanced driver-assistance systems (ADAS), or other automotive applications.

With the soft start (SS) function, the MPQ5071N-AEC1 can avoid inrush current during start-up. The device also provides a configurable soft-start time, output discharge functions, over-current protection (OCP), and thermal shutdown.

The maximum load at the output (N-channel MOSFET source) is limited via an internal current limit. This is accomplished by utilizing a sensing FET topology. An internal charge pump drives the gate of the power device, allowing a very low R_DS(ON) DMOS power FET.

The MPQ5071N-AEC1 is available in a tiny, space-saving SOT563 package, and is available in AEC-Q100 Grade 1.

产品特性和优势

Extends Vehicle Battery Life:
- Extremely Low 0.01µA Shutdown Current
• Reduces Board Size:
- Available in an SOT563 Package
Flexibility:
- Single Channel with 1A of Nominal Current
- Adjustable Start-Up Slew Rate
- Output Discharge
Full Diagnostics and Protections:
- Short-Circuit Protection (SCP)
- Internal Current Limit
- Thermal Shutdown
- Available in AEC-Q100 Grade 1
Functional Safety System Design Capable:
- MPSafe^TM-Compatible – Functional Safety Supporting Document Available
