mEZD71210A-A

正在供货

4.5V - 17V Input, 1V Output, 10A, DC/DC Power Supply

  • 数量 单价
  • 1
    ¥ 64.78 /unit

有货

1周左右到货。
每单运费仅为 5 美元。


咨询工程师或询价

产品描述

The mEZD71210A is an open-frame, 4.5-17V input step-down power module with 10A continuous output current with 1.0V output voltage. It features output voltage and current readback, programmable current limit and frequency via I2C. It provides up to 93% peak efficiency.

产品特性

  • 4.5V to 17V Wide Operating Input
  • 10A Load Current
  • Hiccup Short-Circuit Protection
  • Over-/Under-Voltage Protection
  • Over-Current Protection
  • Over-Temperature Protection
  • Open Design Files and BOM

技术参数

  • Module Assembly Open Frame
  • 最小输入电压4.5
  • Vin (max) (V)17
  • Vout (min) (V)1
  • Vout (max) (V)1
  • 额定输出1
  • Iout (max) (A)10
  • fsw (min) (kHz)500
  • fsw (max) (kHz)500
  • I2C InterfaceNo
  • PGYes
  • SS内部
  • Operating Junction Temp Range (°C) -40 to 125
  • PackageSiP
  • Dimension WxL (mm)26.40x20
  • Dimension (H) (mm)1.6
  • Mounting TypeSIP
  • GradeIndustrial
  • Special FeaturesOCP, OTP, SCP
质量方针和证书
所有 MPS 产品都保证无铅,无卤素,并且遵守 RoHS 规范。详情请见“环境认证”。
