MPQ79710FS-AEC1

MPQ79710FS-AEC1

MPSafe^TM, ASIL-D, 10-Channel Power Sequencer, AEC-Q100 Qualified

详情

The MPQ79710FS-AEC1 is a 10-channel, functional safety power sequencer engineered to provide precise power sequencing and safety functions for automotive advanced driver-assistance systems (ADAS) and autonomous driving platforms. The device’s configurability and flexibility help enable design reuse across different applications and system-on-chip (SoC) generations.

It includes a crystal driver, a real-time clock (RTC) with an alarm function, a configurable watchdog accessible via the I²C interface, and active-low system reset and interrupt outputs.

Safety mechanisms such as built-in self-testing (BIST) provide high diagnostic coverage, which helps the system achieve its target ASIL rating.

The MPQ79710FS-AEC1 is available in a QFN-24 (4mmx4mm) package with wettable flanks, and is available in AEC-Q100 Grade 1.

产品特性和优势

Designed for Automotive ADAS and Autonomous Driving Platforms:
- 2.7V to 5.5V Input Voltage (V_IN) Range
- 10 Enabled Outputs
- Time Slot Based Sequencing
- System Reset Signal
- System Interrupt Signal
Mission-Critical Safety Features:
- Write Protection on Safety Critical Registers
- Advanced Diagnostics
- Built-In Self-Testing (BIST)
- Window Watchdog Timer
- Over-Temperature (OT) Shutdown
- Support Systems Up to ASIL-D
- ISO 26262 Functional Safety Compliant
Application Flexibility with I²C Interface:
- Fast Mode I²C Interface with Cyclic Redundancy Check (CRC)
- One-Time Programmable (OTP) Memory
Configurable Parameters:
- Sequence Order
- I²C Address
- Watchdog Timing
- Drive Mode for Enabled Pins
- Alternate Functions for Enabled Pins
Additional Features:
- Battery Backup Input
- 32kHz Crystal Oscillator Driver
- Real-Time Clock (RTC)
- Available in a QFN-24 (4mmx4mm) Package
- Packaged with a 0.5mm Pitch and Wettable Flanks
- Available in AEC-Q100 Grade 1
MPSafe^TM:
- Developed for Functional Safety Applications: ISO 26262 Compliant
